ADAM Audio S5H Dual 10 inch 3-way Powered Studio Monitor

$10,399

In Stock

Quick Overview

Active Horizontal 3-way Main Monitor with 2 x 350W 10″ Woofers, 300W 4″ Midrange, 100W S-ART Folded-ribbon Tweeter, and Custom DSP Engine (each)

Available on backorder

Adam Professional Audio S5H Specs
Studio Monitor
Monitor Type Active 3-Way
Enclosure Bass-Reflex, Shielded
Drivers HF Driver: 1 x 2″ / 50.8 mm Ribbon Tweeter
MF Driver: 1 x 4″ / 100 mm Composite Dome/Cone Hybrid with 2.4″ / 60 mm Voice Coil
LF Driver: 1 x 10″ / 265 mm HexaCone Woofer with 3″ / 76 mm Voice Coil
Amplification HF Amplifier: Class-D Rated at 100 W
MF Amplifier: Class-D Rated at 300 W
2 x LF Amplifier: Class-D Rated at 700 W
Performance
Frequency Range 22 Hz to 50 kHz
Maximum Sound Pressure Level (SPL) 131 dB
Total Harmonic Distortion (THD) 0.3%
Maximum Input Level +24 dBu
Signal Processing
EQ 1 x HF Shelf dB
1 x LF Shelf dB
Crossover
Crossover Frequency Low-Pass: 250 Hz
High-Pass: 3 kHz
Connectivity
Audio I/O 1 x XLR Analog Input (48 Kilohms)
1 x XLR AES/EBU Digital Input
1 x XLR AES/EBU Digital Output
USB & Network I/O 1 x USB Type-B (Remote)
Power
AC Input Power 100 to 240 VAC, 50/60 Hz
Power Consumption 900 W (Maximum)
General
Dimensions (W x H x D) 34.8 x 16.9 x 19.7″ / 885 x 430 x 500 mm
Weight 160.0 lb / 72.6 kg

Product Description

The S5H from Adam Professional Audio is an active studio reference monitor designed for horizontal orientation in medium-sized and large control rooms. Capable of delivering 1800W RMS of cumulative amp power, it features two 10” HexaCone woofers, one 4” dome/cone hybrid midrange driver, and a handmade folded-ribbon tweeter. The waveguides, Adam-designed mid- and high-range propagation systems (MPS and HPS), ensure a wide, stable sweet spot.

Developed for transparency, the S5H’s frequency response is an impressive 22 Hz to 50 kHz. A multitude of DSP options, from equalization to delay, are provided for tailoring the monitor to the room and to personal preferences. The back panel features an OLED display and a push-button/rotary encoder to allow modification of parameters. Connect a computer to the USB Type-A jack for convenient remote access to all the S5H’s settings.

Two inputs, balanced analog and AES3 digital, are available via XLR jacks. An XLR AES3 output is provided to route digital signal to the second monitor, necessary for correct digital signal flow. Vary input sensitivity and output level as needed. Load and save voicing presets for quick configuration of monitor options. If further tonal adjustments are desired, there is a 6-band parametric EQ with high-pass and low-pass filters. Use up to 5 ms of delay for timing adjustments.

Adam S Series monitors, custom-developed with no off-the-shelf components, are handmade in Berlin according to strict manufacturing tolerances.

2 x 10″ ELE (Extended Linear Excursion) HexaCone woofers
Redesigned bass reflex tubes minimize resonance and signal loss
4″ carbon composite DCH (Dome/Cone Hybrid) midrange driver
Aluminum MPS (Midrange Propagation System) waveguide
S-ART folded ribbon tweeter with aluminum HPS (High-frequency Propagation System) waveguide
1800W RMS cumulative power via four PWM (Class D) amplifiers
2 x 700W woofer amps
300W midrange amp
100W tweeter amp
24 Hz – 50 kHz frequency response
Low harmonic distortion
Adjustable input sensitivity and output level
6-band parametric equalizer with HPF and LPF filters
Variable delay for timing adjustment
XLR analog and AES3 digital inputs
USB Type-A for remote access via computer
