Warm Audio WA-47jr-Black FET Condenser Microphone
$349.00
Transformerless Large-Diaphragm FET Condenser Microphone with 3 Polar Patterns, 10dB Pad, and 70Hz Highpass Filter – Black
-
Contemporary Version Of A Classic Sound
The WA-47jr series is a contemporary version of the legendary 47-style studio microphone that delivers rich analog tone with modern circuitry. WA-47jr & WA-47jr SE mics are equally at home in a project studio or in a world-class recording facility. Each features a vintage-correct reproduction of the lauded K47-style capsule, the same capsule in the flagship WA-47 tube mic. The capsule has the same tonal character known for capturing legendary recordings by classic and modern artists including The Beatles, Billie Eilish, Harry Styles, Adele and many more.
-
Delivering a Legacy Of Studio Sound
Combining possibly the greatest classic condenser capsule of all time with our carefully crafted, modern circuits, the WA-47jr mics deliver that analog warmth and pristine detail for capturing everything from vocals, to toms, to acoustic guitar. Available with onboard controls and multiple patterns or a streamlined cardioid-only design, the WA-47jr mics all have a discrete signal path, exceptional dynamic range, and ultra-low self-noise. The sound profile of the WA-47jr series blends past and present to achieve the ideal blend of vintage tone and modern performance.
-
Applications
The WA-47jr series is built around the same vintage-accurate K47-style capsule in our flagship WA-47 mic. The WA-47jr offers additional controls and multiple polar patterns, while the WA-47jr SE delivers a streamlined cardioid-only design of this classic tone.
- WA-47jr
- Contemporary Version Of The Classic ’47-Style Studio Mic
- Large-Diaphragm FET Transformerless Condenser Microphone
- Polar Patterns: Cardioid, Figure-8, & Omnidirectional
- -10 dB Pad | 70 Hz High-Pass Filter
- Weight: 1.1 Lbs | Diameter: 52mm | Length: 210mm
- Includes: Shockmount, Hard Mount, Leather Storage Pouch
- WA-47jr SE
- Streamlined Version Of The Classic ’47-Style Studio Mic
- Large-Diaphragm FET Transformerless Condenser Microphone
- Cardioid-Only Polar Pattern
- Includes: Hard Mount, Leather Storage Pouch
- WA-47jr
- Gold-Sputtered, Large-Diaphragm, Dual-Backplate, K47-Style Capsule
- Capsule Makeup: Dual Large-Diaphragm, Single-Backplate, 6 Microns NOS Mylar (PET Film)
- Fully Discrete Signal Path, Toshiba FET’s, Wima Film Capacitors, Panasonic Electrolytic Capacitors
- WA-47jr SE
- Gold-Sputtered, Large-Diaphragm, Single-Backplate, K47-Style Capsule
- Fully Discrete Signal Path, Toshiba FET’s, Wima Film Capacitors
- WA-47jr
- Self-Noise: 9dBA
- Dynamic Range: 138dBA
- Maximum SPL: 147/157dB (@1kHz 1kOhms 0.5% THD, 0/-10dB)
- Frequency Range: 20 Hz~20 KHz
- Sensitivity: 10mV/Pa Or -40dB
- Output Impedance: 100 Ohms
- Rated Load Impedance: ≥1kOhms
- Equivalent Noise: 10dBA (IEC651)
- WA-47jr SE
- Self-Noise: 9dBA | Dynamic Range: 138dBA
- Maximum SPL: 147 dB
- Frequency Range: 20 Hz~20 KHz
- Output Impedance: 100 Ohms
- Sensitivity: -37dBV or 14mV/Pa
