Lewitt CONNECT 2 Type-C Audio Interface
$219.00
The most user-friendly type-C audio interface with a compressor and denoiser
Available on backorder
The most user-friendly audio interface.CONNECT 2
- USB-C audio interface
- Autosetup for sensational sound with just a few clicks
- Clipguard protects from distortion
- Single-click Compressor and Denoiser
- Three iconic preamp sounds
- Touch-based and intuitive controls
- Custom button for workflow shortcuts
- Individual LED colors and brightness
Sensational sound with just a few clicks.
CONNECT 2 is the most user-friendly audio interface for musicians and content creators. It combines great usability, powerful features, and incredible specs.
Comes with CONTROL CENTER software and all the tools to make you sound sensational with just a few clicks.
Autosetup dials in your optimal settings.
With CONNECT 2, you don’t need an audio engineering degree to sound great. Run Autosetup and quickly find your perfect settings with the help of the integrated Clipguard, Denoiser, Compressor, and three iconic preamp sounds.
-
Device
- Features
- RGBW LEDs, MUTE, custom button, autogain, input / playback mix, gain reduction display, Kensington lock
- Control
- Capacitive touch
- Inputs
- 1x Microphone: balanced 3-pin XLR, 1x Instrument: Hi-Z 6.3 mm jack
- Outputs
- 2x Speaker: 6.3 mm balanced jack, 1x Headphone: 6.3 mm jack, 1x Headphone: 3.5 mm jack
- Metering
- 25 step high-resolution
- Dimensions and weight
- 151 x 110 x 41 mm, 394 g
- Power requirements
- USB bus-powered
-
Digital
- Type
- USB-C audio interface
- Software
- LEWITT CONTROL CENTER
- DAW included
- Steinberg Cubase LE, Cubasis LE
- Compatibility
- MacOS, Windows, iOS (plug and play with USB-C devices, devices with lightning connector require Camera Connection Kit and external bus power)
- ASIO driver
- Yes
- Sample rate
- 44.1 kHz, 48 kHz, 96 kHz
- Bit rate
- 24
- USB Audio Class
- 2.0
- Signal flow
- Input / playback mix
- DSP powered
- Yes
- Loopback
- Yes
- Inputs / Outputs
- 4 (includes 2 software channels) / 2
- Streaming modes
- macOS mode, mobile mode
- Min. system requirements
- Windows 10 (64 bits): 4 GB RAM minimum, USB 2.0 connector; macOS 10.15 and higher: 4 GB RAM minimum, USB 2.0 connector
-
Microphone Input
- Features
- DSP (low-cut filter, clipguard, preamp modes, denoise, compressor, autogain, autosetup)
- Type
- balanced
- Connector
- 3-pin XLR
- Phantom power
- 48 V
- Gain range
- 0 – 72 dB
- Equivalent input noise
- –129 dBV (A)
- Dynamic range
- 118 dB (A) – Without clipguard 118 dB (A)
- Max input level
- 15.8 dBV
- Total harmonic distortion
- 0.001%
- Frequency response
- 20 Hz – 20 kHz (± 0.1 dB)
-
Instrument Input
- Features
- DSP (low-cut filter, clipguard, preamp modes, denoise, compressor, autogain, autosetup)
- Type
- Hi-Z, differential ground loop break circuit
- Connector
- 6.3 mm jack
- Gain range
- 0 – 60 dB
- Input impedance
- 2.5 M Ω
- Equivalent input noise
- –108 dBV (A)
- Dynamic range
- 121 dB (A) – Without clipguard 105 dB (A)
- Max input level
- 12.5 dBV
- Total harmonic distortion
- 0.0008%
- Frequency response
- 20 Hz – 20 kHz (± 0.1 dB)
-
Speaker Output
- Features
- High volume speaker mode, Mute, Volume, Map system volume controls
- Connector
- 2x 6.3 mm jack, balanced
- Frequency response
- 20 Hz – 20 kHz (± 0.1 dB)
- Max output level
- 12.2 dBV (high volume mode)
- Total harmonic distortion
- 0.0023%
- Impedance
- 200Ω
-
Headphone Output
- Features
- High impedance headphone mode, Mute, Volume, Map system volume controls
- Connector
- 1x 6.3 mm jack, stereo, 1x 3.5 mm jack, stereo
- Frequency response
- 20 Hz – 20 kHz (± 0.2 dB)
- Max output level
- 6.8 dBV (high impedance mode)
- Total harmonic distortion
- 0.003%
- Impedance
- 1.9 Ω
