PreSonus StudioLive® Series III 32SC Digital Console Mixer
$2,399.99
Portable powerhouse 32-channel digital mixer with built-in 128-channel (64×64) USB interface with a complete suite of integrated software
Available on backorder
Overview
A 40-channel powerhouse packed inside a portable, rack-mountable frame, the StudioLive 32SC is a compact digital mixer that can compete with its bigger brothers, particularly when you consider its price. Thanks to AVB, it’s easily expandable – readily networking with EarMix 16M personal monitor mixers for customized onstage mixes and PreSonus NSB-series stage boxes for additional inputs. The StudioLive 32SC’s 16 FlexMixes can be individually configured to function as aux buses, subgroups, or matrix mixes – your routing options will border on limitless. The Fat Channel processing section employs expandable, plug-in options with vintage-style EQ and classic compression options on every input channel and output bus.
The StudioLive 32SC also ships with PreSonus Capture® recording software, which can be run directly on your mixer or Windows or Mac computer. Record all 32 channels plus a stereo mix of your choosing via USB, to an SD Card, or both for the ultimate redundant live recording rig.
Features
- Portable, and flexible digital console for installed sound, mobile applications, and recording with dual-core FLEX DSP Engine powering 286 simultaneous processors
- Fully recallable, 38-input, 40-channel digital mixing console
- 24 Mix buses: 16 FlexMixes (Aux-, Matrix-, or Subgroup- configurable), 4 FX Mixes, 4 Subgroups
- 17 touch-sensitive, motorized faders
- Built-in 64×64 AVB audio networking makes connecting other StudioLive Series III mixers, PreSonus NSB stage boxes, EarMix 16M personal monitor mixers plug-and-play
- Built-in 128-channel (64×64) USB interface – the most of any digital mixer on the market
- Onboard multitrack SD Card recorder with true Virtual Soundcheck
- FLEX FX multi-effects processor with 4 slots to load legendary reverb emulations and delays with 4 dedicated effects buses
- Complete professional solution: suite of integrated software, including 12 months of Studio One® Pro and Capture®
Studio One Pro 7 DAW Software License Included.
Your hardware registration includes a Studio One Pro 7 perpetual license (yours to keep) and 12 months of access to all the add-ons, exclusive content, and extras in Studio One Pro+.
Electronic
-
Headphone Jack: 1/4″ TRS Active Stereo
-
Phantom Power: +48 VDC (±2 VDC)
-
Power Consumption: 85W (Continuous)
-
VoltageRequirements: 100-230 VAC, 50-60 Hz
General
- Color: Gray
- Product Name: StudioLive® Series III 32SC Digital Console Mixer, Gray
- Series: StudioLive
Hardware
-
Digital Audio AES EBU Output: XLR Male
-
Digital Audio AVB Audio Network Ports: Locking XLR, Ethernet
-
Digital Audio Network Control Port: RJ-45
-
Digital Audio USB Recording Port: USB 2.0, Type-B
-
Tape Connection Type: RCA Female, Unbalanced (Stereo Pair)
Input
-
Line Input Connection Type: 1/4″ TRS Female, Balanced
-
Line Inputs Frequency Response: 20-20 kHz (±0.5 dBu at Unity Gain)
-
Line Inputs Impedance: 10 kΩ
-
Line Inputs Maximum Level: =+18 dBu
-
Line Inputs Signal To Noise Ratio: 94 dB (Ref =+4 dB, 20 kHz BW, Unity Gain, A-Weighted)
-
Line Inputs Total Harmonic Distortion: <0.005%, +4 dBu, 20-20 kHz, Unity Gain, Unweighted
-
Microphone Input Connection Type: XLR Female, Balanced
-
Microphone Preamp Common Mode Rejection Ratio: 65 dB (1 kHz at Unity Gain)
-
Microphone Preamp Frequency Response: 20-20 kHz (±0.5 dBu at Unity Gain)
-
Microphone Preamp Gain Control Range: 0 dB to 60 dB (±1 dB)
-
Microphone Preamp Input Impedance: 1 kΩ
-
Microphone Preamp Maximum Input Level: =+12 dBu (Unity Gain)
-
Microphone Preamp Signal To Noise Ratio: 94 dB (Ref = +4 dB, 20 kHz BW, Unity Gain, A-Weighted)
-
Microphone Preamp Total Harmonic Distortion: <0.005%, +4 dBu, 20-20 kHz, Unity Gain, Unweighted
-
Tape Maximum Input Level: +12 dBu, ±0.5 dBu
Measurements
-
Product Depth: 22.97” (583.84 mm)
-
Product Height: 6.51” (165.36 mm)
-
Product Width: 17.59” (446.66 mm)
Miscellaneous
-
Digital Audio Internal Processing: 32-Bit, Floating Point
-
Power Cable: IEC
-
Recommended Ambient Operating Temperature: 0˚ to 40˚ Celsius / 32˚ to 104˚ Fahrenheit
-
Supported Sample Rates: 48 kHz, 44.1 kHz
Output
-
Headphone Outputs Frequency Response: 20 Hz to 20 kHz, +/-0.5 dB
-
Headphone Outputs Maximum Output: 100 mW/ch. @ 60Ω load
-
Headphone Outputs Signal To Noise Ratio: 96 dB, 1 kHz, Maximum Gain, 20 Hz BW, Unweighted
-
Headphone Outputs Total Harmonic Distortion: 0.01%, 1 kHz, Maximum Gain, 20 Hz BW, Unweighted
-
Line Outputs Connection Type: 1/4″ TRS Female, Balanced
-
Line Outputs Maximum Output Level: =+18 dBu, ±0.5 dBu
-
Line Outputs Output Impedance: 100 Ohms
-
Tape Maximum Output Level: +18 dBu, ±0.5 dBu
-
Tape Output Impedance: 100 Ohms
-
XLR Outputs Maximum Output Level: +24 dBu, ±0.5 dBu
-
XLR Outputs Output Impedance: 100 Ohms
Performance
-
Crosstalk (Adjacent Channels): -87 dB (Reference = +4 dBu, 20 Hz-20 kHz, Unweighted)
-
Digital Audio Bit Depth: 24
-
Digital Audio Dynamic Range: ADC Dynamic Range: 115 dB (A-Weighted, 48 kHz), DAC Dynamic Range: 115 dB (A-Weighted, 48 kHz)
-
Digital Audio Reference Level For Zero dBFS: =+18 dBu
-
Digital Audio Total System Latency:1.9 ms (local routing, analog in-analog out, all processing active)
Document Download:
QMix UC Reference Manual – StudioLive 32SC (English)
Tech Sheet – StudioLive 32SC (English)
Advanced AVB Integrator Application Guide (English)
UC Surface Reference Manual (English)
Audio Interface Mode and WDM Guide for StudioLive Series III Mixers (English)
Networking for StudioLive Remote Control V2 (English)
Series III Mixer Comparison Chart
StudioLive Series III AVB Networking Guide (English)
