Focusrite Scarlett 18i20 4th Gen USB-C Audio Interface
$679.00
26-in/26-out, 24-bit/192kHz, USB-C Audio Interface with 8 Preamps, Auto Gain, Clip Safe, Dynamic Halos, and Included Software – macOS/Win
Available on backorder
Description
Description
Scarlett 18i20 is the ultimate studio hub for demanding project studios. Fully equipped with 26 inputs and 26 outputs, including eight of our most detailed ultra-low-noise mic preamps, line, Hi-Z, and MIDI connections for your drums, vocals, guitars, keys, and synths. Focusrite Control 2 provides flexible routing and mixing options, allowing you to customise 18i20’s independent outputs to suit the needs of any recording session. Expand and sync your setup with ADAT, S/PDIF, and Word Clock connections.
Air mode, with Presence and Harmonic Drive, brings the sound of big studio consoles to your recordings, while Auto Gain and Clip Safe ensure you never worry about levels. Low-latency monitoring, A/B speaker switching, and a built-in talkback mic are perfect for serious project studios. The Hitmaker Expansion software bundle has all the tools you need to record, produce, and release your tracks. And the Focusrite Control 2 desktop and mobile apps enable you to remotely control your Scarlett anywhere in the studio.
Eight of our most detailed, ultra-low-noise preamps.
Auto Gain and Clip Safe.
Specification
Specifications
Overview
- Number of Microphone Preamps8
- Phantom PowerYes (Independent)
- Instrument Inputs2
- Line Inputs8
- Air ModeYes
- Auto GainYes
- Clip SafeYes
- Line Outputs10
- Headphone Outputs2
- ADAT Inputs2 (16 channels at 44.1/48kHz and up to 8 channels at 96kHz)
- ADAT Outputs2 (16 channels at 44.1/48kHz and up to 8 channels at 96kHz)
- SPDIF Inputs1
- SPDIF Outputs1
- MIDI Inputs1
- MIDI Outputs1
- TalkbackYes
- LoopbackYes
- ConnectivityUSB Type-C
- ProtocolUSB 2.0
- Form FactorDesktop / Rack Mountable (1U)
- Simultaneous I/O26 x 26
- A/D Resolution24-bit/192 kHz
- Bus PoweredNo
Dimensions
- Height46.55mm
- Width442mm
- Depth259.73mm
- Weight3.304kg
Supported sample rates
- 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
Microphone inputs
- Frequency Response20-20kHz ± 0.06dB
- Dynamic Range116dB (A-Weighted)
- THD+N-100dB @ 8dB gain
- Noise EIN-127dBu (A-Weighted)
- Maximum Input Level16dBu
- Gain Range69dB
- Impedance3kΩ
Variable Line inputs
- Frequency Response20-20kHz ± 0.05dB
- Dynamic Range115.5dB (A-Weighted)
- THD+N-100dB @ 8dB gain
- Maximum Input Level22dBu
- Gain Range69dB
- Impedance24kΩ
Instrument inputs
- Frequency Response20-20kHz ± 0.05dB
- Dynamic Range113dB (A-Weighted)
- THD+N-80dB @ 8dB gain
- Maximum Input Level12dBu
- Gain Range62dB
- Impedance1MΩ
Line outputs (Balanced)
- Frequency Response20-20kHz ± 0.02dB
- Dynamic Range122dB (A-Weighted)
- THD+N-112dB
- Maximum Output Level16dBu
- Impedance200Ω
Headphone outputs
- Frequency Response20-20kHz ± 0.1dB @ 33Ω / 300Ω
- Dynamic Range112dB @ 33Ω
116dB @ 300Ω - THD+N-100dB @ 33Ω (Minimum)
-110dB @ 300Ω (Minimum) - Maximum Output Level5dBu into 33Ω
11dBu into 300Ω - Maximum Output Power57mW into 33Ω
27mW into 300Ω - Impedance11Ω
Analogue to Digital Converter
- THD+N-110dB
- Dynamic Range120dB
Digital to Analogue Converter
- THD+N-115dB
- Dynamic Range130dB (A-Weighted)
Power
- External30W
What’s in the box
- Scarlett 18i20 audio interface
- Rack Ears
- 1.5m USB-C to USB-C cable
- USB-C to USB-A adaptor
- IEC power cable
